ASSR-301C-503E

Broadcom Limited
RoHS
RoHS RoHS compliant
Package 4-SOP (0.173, 4.40mm)
Category Relays / Solid State Relays
Description RELAY SSR SPST SGL 0.05A 4-SOP
PDF
/
Buying Options
Total Price: USD $3.31
Unit Price: USD $3.311134
≥1 USD $3.311134
≥200 USD $1.28139
≥500 USD $1.236752
≥1500 USD $1.214433
Inventory: 3188
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 17 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 4-SOP (0.173, 4.40mm)
Number of Pins 4

Technical

Packaging Tape & Reel (TR)
Published 2013
Series ASSR
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Gull Wing
ECCN Code EAR99
Resistance 50Ohm
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Additional Feature UL RECOGNIZED
Termination Style Gull Wing
Output Type AC, DC
Max Output Current 50mA
Number of Elements 1
Circuit SPST-NO (1 Form A)
Voltage - Input 1.3VDC
Output Current 50mA
Throw Configuration SPST
Input Type DC
Optoelectronic Device Type TRIGGER OUTPUT SSR
Max Output Voltage 250V
Max Input Voltage 1.65V
Relay Type Relay
Voltage - Load 0V~250V
Forward Current-Max 0.01A
On-State Resistance (Max) 50Ohm
Max Input Current 10mA
Overall Height 2mm
Input Current 10mA
On-State Current-Max 0.05A
Isolation Voltage 3.75kV
Control Current 0.001A

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
