2106112-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Solid State Lighting Connectors
Description
CONN SSL HDR 2POS 3.5MM SOLDER
PDF
/
Buying Options
Total Price: USD $3.4
Unit Price: USD $3.3968
≥1 USD $3.3968
≥10 USD $3.028731
≥100 USD $2.688822
≥500 USD $2.472448
≥1000 USD $2.209759
Inventory: 1511
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
PCB Thickness 1.5748mm
Width 20.77mm
Length 17.54mm
Height 20.6756mm
Technical
Make First / Break Last No
Keyed Yes
Mating Post Length 6.477mm
Mating Cycles 30
Contact Current Rating 5A
Sealable Yes
Max Voltage Rating (DC) 250V
Max Current Rating 5A
Max Voltage Rating (AC) 250V
ELV Compliant
Housing Color Black
Number of Contacts 2
Contact Finish Tin
Current Rating 5A
Style Board to Cable/Wire
Depth 6.96mm
Ingress Protection IP67 - Dust Tight, Waterproof
Orientation Straight
Pitch 0.138 3.50mm
Current Rating (Amps) 3.5A 22-24AWG ; 5A 18-20AWG
Fastening Type Latch Lock
Voltage - Rated 400V
Gender Male
Number of Rows 1
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 221°C
Number of Positions 2
Connector Type Header, Male Pins
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Lock
Series SlimSeal
Published 2010
Packaging Tube
Operating Temperature -40°C~105°C
Physical
Housing Material Liquid Crystal Polymer (LCP)
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 16 Weeks
