2008563-2 image
Favorite
2008563-2 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Solid State Lighting Connectors
Description LED Interconnection RCP 1 POS RA
PDF
/
Buying Options
Total Price: USD $0.93
Unit Price: USD $0.9328
≥1 USD $0.9328
≥10 USD $0.60632
≥100 USD $0.397496
≥500 USD $0.313799
≥1000 USD $0.292882
≥3000 USD $0.282418
Inventory: 1533
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No

Dimensions

Width 3.9624mm
Length 14.224mm
Height 3.9mm

Technical

Preloaded Yes
Insulation Diameter 2.09804 mm
Contact Current Rating 4A
Sealable No
Wire/Cable Gauge 22 AWG
Wire Gauge (Min) 18 AWG
Wire Gauge (Max) 20 AWG
Wire/Cable Type Discrete
ELV Compliant
Wire Gauge 18 AWG, 20 AWG, 22 AWG
Operating Supply Voltage 250V
Housing Color Black
Number of Contacts 1
Approval Agency CSA
Voltage - Rated AC 250V
Contact Finish Tin
Current Rating 4A
Style Board to Cable/Wire
Depth 10.5mm
Orientation Right Angle
Current Rating (Amps) 4A
Voltage - Rated 250V
Gender Receptacle
Number of Rows 1
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 221°C
Number of Positions 1
Connector Type Receptacle, Poke-In Wire
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2008
Packaging Tape & Reel (TR)
Operating Temperature -40°C~105°C

Physical

Housing Material Liquid Crystal Polymer (LCP)
Material Liquid Crystal Polymer
Mounting Type Surface Mount, Right Angle
Mount Surface Mount
Contact Plating Tin
Contact Material Copper Alloy

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 11 Weeks
