1-2213301-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Solid State Lighting Connectors
Description
TE CONNECTIVITY / AMP 1-2213301-2CONNECTOR, RECEPTACLE, 2 POSITION, 1ROW, 4MM
PDF
/
Buying Options
Total Price: USD $1.55
Unit Price: USD $1.546169
≥1 USD $1.546169
≥10 USD $1.458646
≥100 USD $1.376082
≥500 USD $1.298193
≥1000 USD $1.224704
Inventory: 9229
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Width 11.9mm
Length 14.64818mm
Technical
Mating Retention Without
Sealable No
Plating Tin
ELV Compliant
Wire Gauge 18 AWG, 20 AWG, 22 AWG
Operating Supply Voltage 250V
Housing Color White
Number of Contacts 2
Contact Finish Tin
Current Rating 9A
Style Board to Cable/Wire
Orientation Horizontal
Pitch 0.157 4.00mm
Current Rating (Amps) 5A 9A
Voltage - Rated 600V
Gender Receptacle
Number of Rows 1
Number of Positions 2
Connector Type Receptacle, Poke-In Wire
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2014
Packaging Tape & Reel (TR)
Operating Temperature -40°C~105°C
Physical
PCB Mount Alignment Without
PCB Mount Retention Without
Housing Material Liquid Crystal Polymer (LCP)
Mounting Type Surface Mount, Right Angle
Mount Surface Mount
Contact Plating Tin
Contact Material Copper Alloy
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 9 Weeks
