1-1954289-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Solid State Lighting Connectors
Description
CONN SSL RCPT & BLADE 4POS 4MM
PDF
/
Buying Options
Total Price: USD $1.6
Unit Price: USD $1.6016
≥1 USD $1.6016
≥10 USD $1.46344
≥100 USD $1.304952
≥500 USD $1.167971
≥1000 USD $1.045405
≥3000 USD $0.937262
Inventory: 2060
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Contact Material Copper Alloy
Contact Plating Tin
Mount Surface Mount
Mounting Type Board Edge, Surface Mount, Right Angle
Material Thermoplastic
Housing Material Liquid Crystal Polymer (LCP)
PCB Mounting Orientation Right Angle
PCB Mount Retention Without
PCB Mount Alignment Without
Technical
Operating Temperature -40°C~105°C
Packaging Tape & Reel (TR)
Published 2008
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Blade and Receptacle, Hermaphroditic
Number of Positions 4
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Color Black
Number of Rows 1
Gender Receptacle
Voltage - Rated 125V
Current Rating (Amps) 6A
Pitch 0.157 4.00mm
Orientation Right Angle
Depth 19.75mm
Style Board to Board
Current Rating 6A
Contact Finish Tin
Voltage - Rated AC 90V
Approval Agency CSA
Number of Contacts 4
Contact Gender Hermaphroditic
Housing Color Black
Operating Supply Voltage 125V
ELV Compliant
Max Voltage Rating (AC) 125V
Plating Tin
Max Voltage Rating (DC) 125V
Sealable No
Contact Current Rating 6A
Mating Alignment Without
Stackable No
High Temperature Compatible Yes
Make First / Break Last No
Dimensions
Height 3.9mm
Length 15.9mm
PCB Thickness 1.57mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
