RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Solid State Lighting Connectors
Description Pluggable Terminal Blocks PTSM 0,5/ 3-P-2,5 WH
PDF
/
Buying Options
Total Price: USD $1.14
Unit Price: USD $1.144
≥1 USD $1.144
≥10 USD $1.09296
≥100 USD $1.04544
≥500 USD $1.016928
≥1000 USD $0.9504
≥3000 USD $0.874368
Inventory: 999
Minimum: 1
-
+

Technical Details

Dimensions

Width 15mm
Length 16.1mm
Height 8.6mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant

Technical

Terminal and Terminal Block Type BARRIER STRIP TERMINAL BLOCK
Number of Poles 3
Wire Gauge (Min) 20 AWG
Wire Gauge (Max) 26 AWG
Max Current Rating 6A
Max Supply Voltage 250V
Wire Gauge 20-26 AWG
Housing Color White
Approval Agency UL
Current Rating 6A
Style Board to Cable/Wire
Depth 15mm
Orientation Right Angle
Pitch 0.098 2.50mm
Current Rating (Amps) 5A
Fastening Type Detent Lock
Voltage - Rated 150V
Gender Female
Number of Rows 1
Connector Type Plug, Female Sockets
ECCN Code EAR99
Termination Spring-Cage
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series COMBICON PTSM
Published 2014
Packaging Bulk

Physical

Housing Material Polyamide (PA), Nylon
Material Polyamide
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Plating Tin

Supply Chain

Factory Lead Time 4 Weeks
