009176003032006

AVX Corporation
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Solid State Lighting Connectors - Contacts
Description CONN SSL IDC CONTACT 24AWG SLDR
PDF
/
Buying Options
Total Price: USD $1.07
Unit Price: USD $1.0736
≥1 USD $1.0736
≥10 USD $0.9108
≥100 USD $0.817608
≥500 USD $0.668923
Inventory: 4309
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 8 Weeks

Physical

Contact Material Phosphor Bronze
Mount Surface Mount
Mounting Type Surface Mount
Housing Material Polyamide (PA46), Nylon 4/6

Technical

Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series 9176
JESD-609 Code e3
Feature Cap (Cover)
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Termination Solder
ECCN Code EAR99
Connector Type Contact, IDC
Number of Positions 3
Number of Rows 1
Gender Receptacle
Voltage - Rated 250V
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Option GENERAL PURPOSE
Current Rating (Amps) 10A per Contact
Pitch 0.157 4.00mm
Orientation Straight
Depth 5mm
Style Board to Cable/Wire
Current Rating 10A
Contact Finish Tin
Housing Color Black
Wire Gauge 24 AWG
Max Voltage Rating (AC) 300V
Wire/Cable Gauge 24 AWG

Dimensions

Length 12mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
