009176003011106
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Solid State Lighting Connectors - Contacts
Description
AVX INTERCONNECT 009176003011106 Wire-To-Board Connector, 20 AWG, 9176 Series, Surface Mount, Receptacle, 3 Contacts, 4 mm
PDF
/
Buying Options
Total Price: USD $1.07
Unit Price: USD $1.0736
≥1 USD $1.0736
≥10 USD $0.9108
≥100 USD $0.817608
≥500 USD $0.668923
Inventory: 2956
Minimum: 1
-
+
Technical Details
Technical
Option GENERAL PURPOSE
Current Rating (Amps) 10A per Contact
Pitch 0.157 4.00mm
Orientation Straight
Depth 5mm
Style Board to Cable/Wire
Current Rating 10A
Contact Finish Tin
Contact Gender Female
Housing Color White
Wire Gauge 20 AWG
Max Voltage Rating (AC) 250V
Wire/Cable Gauge 20 AWG
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated 300V
Gender Receptacle
Number of Rows 1
Number of Positions 3
Connector Type Contact, IDC
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series 9176
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Dimensions
Length 12mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
Physical
Housing Material Polyamide (PA46), Nylon 4/6
Mounting Type Surface Mount
Mount Surface Mount
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 8 Weeks
