009175003001106
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Solid State Lighting Connectors - Contacts
Description
Conn IDC Connector RCP 3 POS 2.5mm Solder ST SMD Reel/Box
PDF
/
Inventory: 6595
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Phosphor Bronze
Mounting Type Surface Mount
Housing Material Polyamide (PA46), Nylon 4/6
Mounting Option 1 LOCKING
Technical
Operating Temperature -40°C~125°C
Series 9175
JESD-609 Code e3
Feature Cap (Cover)
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Termination Solder
Connector Type Contact, IDC
Number of Positions 3
Number of Rows 1
Voltage - Rated 150V
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Option GENERAL PURPOSE
Current Rating (Amps) 1A per Contact
Pitch 0.098 2.50mm
Total Number of Contacts 3
Orientation Straight
Depth 2.5mm
Style Board to Cable/Wire
Current Rating 1A
Number of Conductors ONE
Reference Standard UL
Contact Finish Tin
Reliability COMMERCIAL
Number Of PCB Rows 1
PCB Contact Pattern RECTANGULAR
Body Breadth 0.098 inch
Contact Gender Female
Housing Color Black
Wire Gauge 26-28 AWG
Max Voltage Rating (AC) 125V
Polarization Key POLARIZED HOUSING
Wire/Cable Gauge 26 AWG
Contact Pattern RECTANGULAR
Insulator Color WHITE
Dimensions
Length 7.5mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
