249159006122906

AVX Corporation
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Solid State Lighting Connectors
Description TIN 9159 ROHS3Compliant UL Socket SSL Connector -40C~125C 5A per Contact 125V 0.153inch
PDF
/
Inventory: 3741
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 8 Weeks

Physical

Contact Material Copper Alloy
Mounting Type Free Hanging (In-Line) - Feed Through
Housing Material Polyamide (PA46), Nylon 4/6, Glass Filled

Technical

Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series 9159
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination IDC
ECCN Code EAR99
Connector Type Socket
Number of Positions 6
Voltage - Rated 125V
Fastening Type Latch Lock
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 5A per Contact
Pitch 0.118 3.00mm
Total Number of Contacts 6
Style Board to Cable/Wire
Shell Finish TIN
Reference Standard UL
Contact Finish Gold
Body Length or Diameter 0.787 inch
Body Breadth 0.153 inch
Contact Gender FEMALE
UL Flammability Code 94V-0
Housing Color White
Empty Shell NO
Body Depth 0.311 inch
Wire Gauge 22 AWG
Mating Cycles 10

Compliance

RoHS Status ROHS3 Compliant
