209159004101116
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Solid State Lighting Connectors
Description
CONN SSL SOCKET 4POS 3MM SOLDER
PDF
/
Buying Options
Total Price: USD $2.38
Unit Price: USD $2.380543
≥1 USD $2.380543
≥10 USD $2.245801
≥100 USD $2.118681
≥500 USD $1.998758
≥1000 USD $1.885616
Inventory: 9118
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Length 14.95mm
Technical
Mating Cycles 10
Max Voltage Rating (AC) 125V
Housing Color White
Contact Finish Gold
Current Rating 5A
Style Board to Board or Cable
Depth 3mm
Orientation Right Angle
Total Number of Contacts 4
Pitch 0.118 3.00mm
Current Rating (Amps) 5A per Contact
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Gender Receptacle
Number of Rows 1
Number of Positions 4
Connector Type Socket
Termination Solder
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
Feature Solder Retention
JESD-609 Code e4
Series 9159
Published 2009
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Housing Material Polyamide (PA46), Nylon 4/6
Mounting Type Surface Mount, Right Angle
Mount Surface Mount
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 8 Weeks
