IPC0102-S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Soldering, Desoldering, Rework Products / Solder Stencils, Templates
Description
QFN-20 STENCIL
PDF
/
Buying Options
Total Price: USD $10.2
Unit Price: USD $10.1992
≥1 USD $10.1992
Inventory: 75
Minimum: 1
-
+
Technical Details
Physical
Material Stainless Steel
Technical
Published 2014
Series Proto-Advantage IPC
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type QFN/LFCSP
Number of Positions 20
Pitch 0.016 0.40mm
Outer Dimension 1.300 L x 0.900 W (33.02mm x 22.86mm)
Dimensions
Thickness 0.0040 0.102mm
Diameter - Inner 0.118 L x 0.118 W (3.00mm x 3.00mm)
Compliance
RoHS Status ROHS3 Compliant
