47-021
RoHS
/
Package /
Category Tools / Sockets, Socket Handles
Description
LEVER BULK PANEL MOUNT-THREADED DPDT Socket 1.61 41.0mm 28V 85C 15A
PDF
/
Inventory: 4818
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Surface Mount NO
Mounting Feature PANEL MOUNT-THREADED
Technical
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
ECCN Code EAR99
HTS Code 8536.50.90.40
Packing Method BULK
Operating Temperature (Max) 85°C
Body Breadth 23 mm
Actuator Type LEVER
Operating Temperature (Min) -40°C
Switch Function DPDT
Contact Current(DC)-Max 15A
Sealing ENVIRONMENTALLY SEALED; IP67; IP64
Contact Voltage(DC)-Max 28V
Termination Type SOLDER/QUICK CONNECT
Electrical Life 6000 Cycle(s)
Switch Type TOGGLE SWITCH
Size 21mm
Tool Type Socket
Contact Current(AC)-Max 15A
Contact (AC) Max Rating R Load 15A@125VAC
Contact (DC) Max Rating R Load 15A@28VDC
Tip - Type 6 Point Socket
Contact Voltage(AC)-Max 125V
Switch Action MOMENTARY
Drive Size 1/2
Dimensions
Length 1.61 41.0mm
Body Height 31.4mm
Compliance
RoHS Status Non-RoHS Compliant
