38-018
RoHS
/
Package /
Category Tools / Sockets, Socket Handles
Description
STANDARD PLUNGER BULK THROUGH HOLE-RIGHT ANGLE DPST Socket 1.13 28.7mm 20V 85C 0.02A
PDF
/
Inventory: 2808
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Body Height 8.65mm
Length 1.13 28.7mm
Technical
Drive Size 3/8
Switch Action MOMENTARY
Contact Voltage(AC)-Max 20V
Tip - Type 6 Point Socket
Contact (DC) Max Rating R Load .02A@20VDC
Contact (AC) Max Rating R Load .02A@20VAC
Contact Current(AC)-Max 0.02A
Tool Type Socket
Size 18mm
Switch Type PUSHBUTTON SWITCH
Electrical Life 60000 Cycle(s)
Termination Type SOLDER
Contact Voltage(DC)-Max 20V
Sealing EPOXY TERMINAL SEALED
Contact Current(DC)-Max 0.02A
Switch Function DPST
Operating Temperature (Min) -30°C
Actuator Type STANDARD PLUNGER
Body Breadth 8.58 mm
Operating Temperature (Max) 85°C
Packing Method BULK
HTS Code 8536.50.90.31
Terminal Finish Gold (Au)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Physical
Mounting Feature THROUGH HOLE-RIGHT ANGLE
Surface Mount NO
