12-416
RoHS
/
Package /
Category Tools / Sockets, Socket Handles
Description
LOCKING LEVER BULK PANEL MOUNT-THREADED 3PDT Socket 1.37 34.8mm 28V 85C 4A
PDF
/
Inventory: 3313
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Dimensions
Body Height 15.1mm
Length 1.37 34.8mm
Technical
Switch Action LATCHED
Contact Voltage(AC)-Max 125V
Tip - Type 8 Point Socket
Contact (DC) Max Rating R Load 4A@28VDC
Contact (AC) Max Rating R Load 4A@125VAC
Contact Current(AC)-Max 4A
Tool Type Socket
Size 1/2
Switch Type TOGGLE SWITCH
Electrical Life 150000 Cycle(s)
Termination Type SOLDER
Contact Voltage(DC)-Max 28V
Sealing EPOXY TERMINAL SEALED; IP67; SPLASH PROOF
Contact Current(DC)-Max 4A
Switch Function 3PDT
Operating Temperature (Min) -40°C
Actuator Type LOCKING LEVER
Body Breadth 16 mm
Operating Temperature (Max) 85°C
Reach Compliance Code compliant
Packing Method BULK
HTS Code 8536.50.90.65
ECCN Code EAR99
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Physical
Mounting Feature PANEL MOUNT-THREADED
Surface Mount NO
