528-AG11D
RoHS
/
Package /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
IC & Component Sockets PC MOUNT 28 PINS
PDF
/
Buying Options
Total Price: USD $18.57
Unit Price: USD $18.574909
≥1 USD $18.574909
≥204 USD $7.411321
≥493 USD $7.164495
≥1003 USD $7.042396
Inventory: 9046
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Contact Material Copper
Mount Through Hole
Mounting Type Through Hole
Housing Material Polyester
Number of Positions or Pins (Grid) 28 (2 x 14)
Contact Material - Mating Copper Alloy
Contact Material - Post Copper Alloy
Technical
Operating Temperature -55°C~105°C
Packaging Tube
Published 2005
Series 500
JESD-609 Code e0
Feature Closed Frame
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type Pin
Type DIP, 0.6 (15.24mm) Row Spacing
Number of Rows 2
Gender Female
Voltage - Rated 1kV
Additional Feature STANDARD: UL 94V-0
HTS Code 8536.69.40.40
Voltage - Rated DC 1kV
Contact Finish - Mating Gold
Orientation Straight
Reach Compliance Code not_compliant
Current Rating 3A
Pitch - Mating 0.100 2.54mm
Lead Pitch 2.54mm
Number of Contacts 28
Contact Finish - Post Tin-Lead
PCB Contact Pattern RECTANGULAR
Body Breadth 0.4 inch
Lead Length 3.175mm
Body Depth 0.18 inch
Contact Resistance 10mOhm
Insulation Resistance 5GOhm
Row Spacing 15.24 mm
Mating Contact Pitch 0.1 inch
Dielectric Withstanding Voltage 1400VAC V
Contact Current Rating 3A
Circuit Application Signal
Termination Post Length 0.125 3.18mm
Pitch - Post 0.100 2.54mm
Dimensions
Length 35.56mm
Plating Thickness 635 nm
Contact Finish Thickness - Mating 25.0μin 0.63μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Flammability Rating UL94 V-0
