1571541-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
PCS-044A-1-LF=44 POS PLCC SCKT
PDF
/
Buying Options
Total Price: USD $4.03
Unit Price: USD $4.028
≥1 USD $4.028
≥10 USD $3.30505
≥100 USD $3.2015
≥500 USD $3.09795
≥1000 USD $2.99535
Inventory: 285
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Post 180.0μin 4.57μm
Contact Finish Thickness - Mating 180.0μin 4.57μm
Length 22.61mm
Height 9.14mm
Technical
Pitch - Post 0.100 2.54mm
Dielectric Withstanding Voltage 600VAC V
ELV Compliant
Insulation Resistance 10000000000Ohm
Contact Resistance 30mOhm
Body Breadth 0.89 inch
Number of Contacts 44
Pitch - Mating 0.100 2.54mm
Current Rating 1A
Depth 22.61mm
Orientation Straight
Contact Finish - Mating Tin
HTS Code 8536.69.40.40
Additional Feature STANDARD: UL 94V-0
Gender Female
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Number of Positions 44
Type PLCC
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Closed Frame
Series PCS
Published 2004
Packaging Bulk
Physical
Contact Material - Post Copper Alloy
Contact Material - Mating Copper Alloy
Number of Positions or Pins (Grid) 44 (4 x 11)
Housing Material Polyphenylene Sulfide (PPS)
Insulation Material Polyphenylene
Mounting Type Through Hole
Mount Through Hole
