1-822473-5
RoHS
/
Package /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
AMP FROM TE CONNECTIVITY 1-822473-5 IC & Component Socket, PLCC Socket, 52 Contacts, 2.54 mm, 19.3 mm, Tin Plated Contacts
PDF
/
Inventory: 5492
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Mount Through Hole
Mounting Type Through Hole
Housing Material Thermoplastic
Number of Positions or Pins (Grid) 52 (4 x 13)
Contact Material - Mating Phosphor Bronze
Contact Material - Post Phosphor Bronze
Technical
Packaging Tube
Published 1998
Feature Closed Frame
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type Socket
Type PLCC
Number of Positions 52
Max Operating Temperature 170°C
Min Operating Temperature -55°C
Number of Rows 4
Gender Female
Voltage - Rated 250V
Contact Finish - Mating Tin
Orientation Straight
Depth 25.72mm
Current Rating 1A
Pitch - Mating 0.050 1.27mm
Voltage - Rated AC 250V
Lead Pitch 2.54mm
Number of Contacts 52
Body Breadth 1.013 inch
Contact Style BELLOWED TYPE
Contact Resistance 20mOhm
Insulation Resistance 1GOhm
Row Spacing 15.24 mm
Max Voltage Rating (AC) 250V
Max Current Rating 1A
Dielectric Withstanding Voltage 830VAC V
Pitch - Post 0.100 2.54mm
Contact Configuration 13X13
Dimensions
Height 8.1mm
Length 25.72mm
Width 25.72mm
Contact Finish Thickness - Mating 100.0μin 2.54μm
Contact Finish Thickness - Post 100.0μin 2.54μm
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
