1-1571552-0
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
Conn DIP Socket SKT 32 POS 2.54mm Solder ST Thru-Hole Tube
PDF
/
Inventory: 2616
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0
Dimensions
Length 40.64mm
Technical
Pitch - Post 0.100 2.54mm
Termination Post Length 0.125 3.18mm
Dielectric Withstanding Voltage 1400VAC V
ELV Compliant
Mating Contact Pitch 0.1 inch
Row Spacing 15.24 mm
Insulation Resistance 5GOhm
Contact Resistance 10mOhm
Contact Style MACHINE SCREW
Lead Length 3.18mm
Body Breadth 0.7 inch
PCB Contact Pattern RECTANGULAR
Number of Contacts 32
Lead Pitch 2.54mm
Pitch - Mating 0.100 2.54mm
Current Rating 3A
Depth 17.78mm
Orientation Straight
Contact Finish - Mating Tin
Capacitance 1pF
HTS Code 8536.69.40.40
Additional Feature STANDARD: UL 94V-0
Gender Female
Number of Rows 2
Type DIP, 0.6 (15.24mm) Row Spacing
Connector Type DIP
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Open Frame
JESD-609 Code e3
Series 800
Published 2009
Packaging Tube
Operating Temperature -55°C~105°C
Physical
Contact Material - Post Copper
Contact Material - Mating Beryllium Copper
Number of Positions or Pins (Grid) 32 (2 x 16)
Housing Material Polycyclohexylenedimethylene Terephthalate (PCT), Polyester
Insulation Material Polychlorinated
Mounting Type Through Hole
Mount Through Hole, Vertical
Supply Chain
Factory Lead Time 14 Weeks
