821949-5 image
Favorite
821949-5 image
Favorite
RoHS
/
Package PQFP
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description Conn PQFP Socket SKT 132 POS 1.91mm Solder ST Thru-Hole Tube
PDF
/
Inventory: 3070
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Material Bronze
Contact Plating Tin
Mount Through Hole
Package / Case PQFP
Insulation Material Polymer
Housing Material POLYETHYLENE
Body Material Thermoplastic

Technical

JESD-609 Code e3
Pbfree Code no
Termination Through Hole
ECCN Code EAR99
Number of Positions 132
Max Operating Temperature 105°C
Min Operating Temperature -55°C
Color Black
Gender Female
Additional Feature POLARIZED
HTS Code 8536.69.40.40
Voltage - Rated DC 750V
Pitch 635μm
Orientation Straight
Depth 34.04mm
Current Rating 1A
Voltage - Rated AC 250V
Lead Pitch 640μm
Number of Contacts 132
Body Breadth 1.34 inch
Contact Style CENTRONIC
Insulation Resistance 5000000000Ohm
ELV Non-Compliant
Max Voltage Rating (AC) 250V
Dielectric Withstanding Voltage 750VAC V
Device Socket Type IC SOCKET
Current Rating (Max) 1A

Dimensions

Height 10.97mm
Length 34.04mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Contains Lead
