2-640379-2
RoHS
/
Package /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
UL 94V-0DIPLOMATE ICs Socket
PDF
/
Inventory: 1935
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length 50.67mm
Technical
Device Socket Type IC SOCKET
PCB Contact Row Spacing 0.6 mm
Dielectric Withstanding Voltage 1000VAC V
ELV Non-Compliant
Insulation Resistance 10GOhm
Contact Resistance 30mOhm
Contact Style BELLOWED TYPE
Lead Length 3.25mm
Body Breadth 0.694 inch
PCB Contact Pattern RECTANGULAR
Number of Contacts 40
Row Spacing - Mating 15.49 mm
Approval Agency CSA, UL
Depth 17.63mm
Orientation Straight
Pitch 2.54mm
Additional Feature UL 94V-0, DIPLOMATE
Number of Rows 2
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 125°C
ECCN Code EAR99
Termination Through Hole
Pbfree Code no
JESD-609 Code e4
Physical
Housing Material GLASS FILLED POLYETHYLENE
Insulation Material Thermoplastic
Mount Vertical
Contact Plating Gold
Contact Material Copper
