ICO-314-SGT
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
Conn DIP Socket SKT 14 POS 2.54mm Solder ST Thru-Hole Tube
PDF
/
Buying Options
Total Price: USD $3.34
Unit Price: USD $3.3352
≥1 USD $3.3352
≥10 USD $3.02632
≥100 USD $2.866336
≥500 USD $2.799808
≥1000 USD $2.6664
≥3000 USD $2.333091
Inventory: 2050
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 30.0μin 0.76μm
Length 17.78mm
Technical
Pitch - Post 0.100 2.54mm
Termination Post Length 0.125 3.18mm
Dielectric Withstanding Voltage 1000VAC V
Mating Contact Pitch 0.1 inch
Row Spacing 7.62 mm
Insulation Resistance 5GOhm
Contact Resistance 10mOhm
Contact Style MACHINE SCREW
Body Breadth 0.395 inch
PCB Contact Pattern RECTANGULAR
Contact Finish - Post Tin
Number of Contacts 14
Pitch - Mating 0.100 2.54mm
Current Rating 1A
Depth 10.03mm
Orientation Straight
Contact Finish - Mating Gold
HTS Code 8536.69.40.40
Additional Feature LOW PROFILE
Gender Female
Number of Rows 2
Type DIP, 0.3 (7.62mm) Row Spacing
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Open Frame
JESD-609 Code e3
Series ICO
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Contact Material - Post Brass
Contact Material - Mating Beryllium Copper
Number of Positions or Pins (Grid) 14 (2 x 7)
Housing Material Polyester, Glass Filled
Insulation Material Polyester
Mounting Type Through Hole
Mount Through Hole
Contact Material Copper
Supply Chain
Factory Lead Time 3 Weeks
