ICF-308-S-O

Samtec Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description SAMTEC ICF-308-S-O IC & Component Socket, ICF Series, DIP Socket, 8 Contacts, 2.54 mm, 7.62 mm, Gold Plated Contacts
PDF
/
Buying Options
Total Price: USD $3.48
Unit Price: USD $3.4848
≥1 USD $3.4848
≥10 USD $3.168
≥100 USD $3.000096
≥500 USD $2.9304
≥1000 USD $2.790832
≥3000 USD $2.441965
Inventory: 39
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 3 Weeks

Physical

Contact Material Copper
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Insulation Material Polymer
Housing Material Liquid Crystal Polymer (LCP)
Number of Positions or Pins (Grid) 8 (2 x 4)
Contact Material - Mating Beryllium Copper
Contact Material - Post Beryllium Copper

Technical

Operating Temperature -55°C~125°C
Packaging Tube
Published 2009
Series iCF
JESD-609 Code e3
Feature Open Frame
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type DIP, Socket
Type DIP, 0.3 (7.62mm) Row Spacing
Number of Rows 2
Gender Female
Additional Feature TIGER EYE CONTACT
Contact Finish - Mating Tin
Orientation Straight
Depth 9.53mm
Current Rating 1A
Pitch - Mating 0.100 2.54mm
Number of Contacts 8
PCB Contact Pattern RECTANGULAR
Body Breadth 0.375 inch
Contact Style RND PIN-SKT
Contact Resistance 10mOhm
Insulation Resistance 5000000000Ohm
Row Spacing 7.62 mm
Mating Contact Pitch 0.1 inch
Dielectric Withstanding Voltage 600VAC V
Pitch - Post 0.100 2.54mm

Dimensions

Length 10.16mm

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
