146-87-306-41-035101
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
146 ROHS3Compliant 2012 RECTANGULAR DIP, 0.3 (7.62mm) Row Spacing Socket UL94V-0 10mOhm -55C~125C 1A
PDF
/
Buying Options
Total Price: USD $1.23
Unit Price: USD $1.2315
≥1 USD $1.2315
≥207 USD $0.492338
≥483 USD $0.47527
≥966 USD $0.467392
Inventory: 2486
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Number of Pins 6
Housing Material Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
Number of Positions or Pins (Grid) 6 (2 x 3)
Contact Material - Mating Beryllium Copper
Contact Material - Post Brass
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2012
Series 146
Feature Open Frame
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
Type DIP, 0.3 (7.62mm) Row Spacing
Contact Finish - Mating Gold
Terminal Pitch 2.54mm
Current Rating 1A
Pitch - Mating 0.100 2.54mm
Body Length or Diameter 0.3 inch
Number of Contacts 6
Contact Finish - Post Tin
PCB Contact Pattern RECTANGULAR
Body Breadth 0.398 inch
Lead Length 3.81mm
Body Depth 0.173 inch
Contact Style RND PIN-SKT
Contact Resistance 10mOhm
Insulation Resistance 10000000000Ohm
Mating Contact Pitch 0.1 inch
Dielectric Withstanding Voltage 1400VAC V
PCB Contact Row Spacing 0.3 mm
Termination Post Length 0.150 3.81mm
Pitch - Post 0.100 2.54mm
Dimensions
Contact Finish Thickness - Mating Flash
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
