614-93-059-11-001001

Mill-Max Manufacturing Corp.
RoHS
/
Package /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description LOW PROFILE ICs Socket
PDF
/
Inventory: 9819
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant

Technical

Contact Configuration 11X11
Device Type Used On PGA59
Device Socket Type IC SOCKET
Contact Finish Termination Tin/Lead (Sn/Pb) - with Nickel (Ni) barrier
PCB Contact Row Spacing 0.1 mm
Dielectric Withstanding Voltage 1000VAC V
Termination Type SOLDER
Mating Contact Pitch 0.1 inch
Insulation Resistance 10000000000Ohm
Contact Style RND PIN-SKT
Body Depth 0.031 inch
Operating Temperature (Min) -55°C
Body Breadth 1.1 inch
Operating Temperature (Max) 125°C
PCB Contact Pattern RECTANGULAR
Number of Contacts 59
Body Length or Diameter 1.1 inch
Current Rating 1A
Terminal Pitch 2.54mm
Contact Finish - Mating GOLD (30) OVER NICKEL (100)
HTS Code 8536.90.40.00
Additional Feature LOW PROFILE
ECCN Code EAR99
Part Status Active
Pbfree Code no
JESD-609 Code e0

Physical

Mounting Style STRAIGHT
Housing Material POLYCYCLOHEXYDIMETHYLENE TEREPHTHALATE-POLYESTER
Contact Material NOT SPECIFIED

Supply Chain

Factory Lead Time 3 Weeks
