D2820-42
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
IC & Component Sockets 20P DR IC SCKT ASSY 2.54MM PITCH
PDF
/
Buying Options
Total Price: USD $2.22
Unit Price: USD $2.2176
≥1 USD $2.2176
≥10 USD $1.92984
≥100 USD $1.80686
≥500 USD $1.724624
≥1000 USD $1.560372
≥3000 USD $1.437181
Inventory: 8501
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper
Mount Through Hole
Mounting Type Through Hole
Insulation Material Polyester
Housing Material Plastic
Number of Positions or Pins (Grid) 20 (2 x 10)
Contact Material - Mating Beryllium Copper
Contact Material - Post Brass
Technical
Operating Temperature -55°C~125°C
Packaging Tube
Published 2009
Series D2
JESD-609 Code e3
Feature Open Frame
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type DIP, Socket
Type DIP, 0.3 (7.62mm) Row Spacing
Number of Rows 2
Additional Feature STANDARD: UL 94V-0
HTS Code 8536.69.40.40
Voltage - Rated DC 150V
Contact Finish - Mating Gold
Orientation Straight
Depth 10.02mm
Current Rating 1A
Pitch - Mating 0.100 2.54mm
Voltage - Rated AC 100V
Number of Contacts 20
Contact Finish - Post Tin
Body Breadth 0.394 inch
Lead Length 3.2004mm
Contact Style RND PIN-SKT
Contact Resistance 10mOhm
Insulation Resistance 10GOhm
Row Spacing 7.62 mm
Dielectric Withstanding Voltage 1400VAC V
Termination Post Length 0.126 3.20mm
Pitch - Post 0.100 2.54mm
Dimensions
Length 25.3mm
Contact Finish Thickness - Mating Flash
Contact Finish Thickness - Post 196.9μin 5.00μm
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
