D2628-42
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
IC & Component Sockets 28 WAY PRESS FIT IC SOCKET
PDF
/
Inventory: 3514
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Contact Material Copper
Mount Through Hole
Mounting Type Through Hole
Number of Pins 28
Housing Material Polycyclohexylenedimethylene Terephthalate (PCT), Glass Filled
Number of Positions or Pins (Grid) 28 (2 x 14)
Contact Material - Mating Beryllium Copper
Contact Material - Post Brass
Technical
Operating Temperature -55°C~125°C
Packaging Tube
Published 1999
Series D26
JESD-609 Code e3
Feature Open Frame
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
ECCN Code EAR99
Type DIP, 0.6 (15.24mm) Row Spacing
Additional Feature STANDARD: UL 94V-0
HTS Code 8536.69.40.40
Contact Finish - Mating Gold
Reach Compliance Code not_compliant
Current Rating 1A
Pitch - Mating 0.100 2.54mm
Number of Contacts 28
Contact Finish - Post Tin
Body Breadth 0.694 inch
Lead Length 2.794mm
Body Depth 0.173 inch
Contact Style RND PIN-SKT
Contact Resistance 10mOhm
Insulation Resistance 10GOhm
Mating Contact Pitch 0.1 inch
Dielectric Withstanding Voltage 1000VAC V
Termination Post Length 0.110 2.78mm
Pitch - Post 0.100 2.54mm
Dimensions
Length 35.5mm
Contact Finish Thickness - Mating 10.0μin 0.25μm
Contact Finish Thickness - Post 196.9μin 5.00μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
