D01-9971042
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
IC & Component Sockets 10P IC SOCKET STRIP 2.54MM PITCH
PDF
/
Buying Options
Total Price: USD $0.64
Unit Price: USD $0.636169
≥1 USD $0.636169
≥10 USD $0.60016
≥100 USD $0.566193
≥500 USD $0.534139
≥1000 USD $0.503906
Inventory: 9423
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Housing Material Polycyclohexylenedimethylene Terephthalate (PCT), Glass Filled
Number of Positions or Pins (Grid) 10 (1 x 10)
Contact Material - Mating Beryllium Copper
Contact Material - Post Brass
Technical
Operating Temperature -55°C~125°C
Packaging Tube
Published 2013
Series D01-997
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Type SIP
Additional Feature STANDARD: UL 94V-0
HTS Code 8536.69.40.40
Contact Finish - Mating Gold
Orientation Straight
Depth 2.54mm
Current Rating 1A
Pitch - Mating 0.100 2.54mm
Number of Contacts 10
Contact Finish - Post Tin
Lead Length 3.175mm
Contact Resistance 10mOhm
Max Current Rating 1A
Termination Post Length 0.125 3.18mm
Pitch - Post 0.100 2.54mm
Dimensions
Length 25.4mm
Contact Finish Thickness - Mating Flash
Contact Finish Thickness - Post 196.9μin 5.00μm
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
