245-20-1-03
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
ROHS3Compliant 2012 Open Frame Tin DIP, 0.3 (7.62mm) Row Spacing Socket 20mOhm -40C~105C 1A 60.0muin 1.52mum
PDF
/
Buying Options
Total Price: USD $0.42
Unit Price: USD $0.4224
≥1 USD $0.4224
≥10 USD $0.3718
≥100 USD $0.319915
≥500 USD $0.30661
≥1000 USD $0.279963
≥3000 USD $0.26664
Inventory: 2363
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Post 60.0μin 1.52μm
Contact Finish Thickness - Mating 60.0μin 1.52μm
Technical
Pitch - Post 0.100 2.54mm
Termination Post Length 0.124 3.15mm
Contact Resistance 20mOhm
Pitch - Mating 0.100 2.54mm
Current Rating (Amps) 1A
Contact Finish - Mating Tin
Type DIP, 0.3 (7.62mm) Row Spacing
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Open Frame
Published 2012
Packaging Tube
Operating Temperature -40°C~105°C
Physical
Contact Material - Post Phosphor Bronze
Contact Material - Mating Phosphor Bronze
Number of Positions or Pins (Grid) 20 (2 x 10)
Housing Material Polybutylene Terephthalate (PBT), Glass Filled
Number of Pins 20
Mounting Type Through Hole, Kinked Pin
Supply Chain
Factory Lead Time 18 Weeks
