211-1-18-003
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
ROHS3Compliant 2012 Open Frame Gold DIP, 0.3 (7.62mm) Row Spacing Socket 4mOhm -55C~105C 3A 10.0muin 0.25mum
PDF
/
Buying Options
Total Price: USD $1.62
Unit Price: USD $1.621432
≥1 USD $1.621432
≥208 USD $0.64726
≥494 USD $0.626253
≥988 USD $0.61575
Inventory: 7710
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Post 200.0μin 5.08μm
Contact Finish Thickness - Mating 10.0μin 0.25μm
Technical
Pitch - Post 0.100 2.54mm
Termination Post Length 0.110 2.78mm
Contact Resistance 4mOhm
Contact Finish - Post Tin
Pitch - Mating 0.100 2.54mm
Current Rating (Amps) 3A
Contact Finish - Mating Gold
Type DIP, 0.3 (7.62mm) Row Spacing
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Open Frame
Published 2012
Packaging Tube
Operating Temperature -55°C~105°C
Physical
Contact Material - Post Brass
Contact Material - Mating Beryllium Copper
Number of Positions or Pins (Grid) 18 (2 x 9)
Housing Material Polybutylene Terephthalate (PBT)
Number of Pins 18
Mounting Type Through Hole
Supply Chain
Factory Lead Time 18 Weeks
