A40-LCG
RoHS
/
Package /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
ICs Socket
PDF
/
Inventory: 3258
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Mount Through Hole
Mounting Type Through Hole
Number of Pins 40
Housing Material POLYBUTYLENE TEREPHTHALATE
Number of Positions or Pins (Grid) 40 (2 x 20)
Technical
Feature Open Frame
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type DIP, 0.6 (15.24mm) Row Spacing
Contact Finish - Mating Gold
Terminal Pitch 2.54mm
Current Rating 1A
Pitch - Mating 0.100 2.54mm
Number of Contacts 40
PCB Contact Pattern RECTANGULAR
Operating Temperature (Max) 105°C
Body Breadth 0.696 inch
Operating Temperature (Min) -55°C
Body Depth 0.201 inch
Contact Style BELLOWED TYPE
Insulation Resistance 1000000000Ohm
Mating Contact Pitch 0.1 inch
Dielectric Withstanding Voltage 500VAC V
PCB Contact Row Spacing 0.6 mm
Pitch - Post 0.100 2.54mm
Dimensions
Height 5.1mm
Length 50.8mm
Width 17.8mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
