C9108-00
RoHS
/
Package /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
CONN IC DIP SOCKET 8POS GOLD
PDF
/
Inventory: 9223
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Wire
Mounting Type Through Hole
Housing Material Polyamide (PA46), Nylon 4/6, Glass Filled
Number of Positions or Pins (Grid) 8 (2 x 4)
Contact Material - Mating Phosphor Bronze
Contact Material - Post Phosphor Bronze
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2003
Series Edge-Grip?, C91
JESD-609 Code e4
Feature Closed Frame
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Termination Wire Wrap
ECCN Code EAR99
Type DIP, 0.3 (7.62mm) Row Spacing
Number of Positions 8
Number of Rows 2
Additional Feature STANDARD: UL 94V-0
Contact Finish - Mating Gold
Current Rating (Amps) 1.5A
Pitch - Mating 0.100 2.54mm
Lead Pitch 2.54mm
Number of Contacts 8
PCB Contact Pattern RECTANGULAR
Body Breadth 0.4 inch
Contact Style SQ PIN-SKT
Insulation Resistance 1000000000Ohm
Mating Contact Pitch 0.1 inch
Dielectric Withstanding Voltage 1000VAC V
PCB Contact Row Spacing 0.3 mm
Termination Post Length 0.675 17.15mm
Pitch - Post 0.100 2.54mm
Dimensions
Height 7.11mm
Length 11.6mm
Width 10.2mm
Contact Finish Thickness - Mating 10.0μin 0.25μm
Contact Finish Thickness - Post 10.0μin 0.25μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Lead Free Contains Lead
