84-PGM13042-50
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
PGM ROHS3Compliant 2009 Gold PGA Socket UL94V-0 105C 3A 10.0muin 0.25mum
PDF
/
Inventory: 3076
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Contact Plating Gold
Mount Through Hole
Mounting Type Through Hole
Housing Material Polyamide (PA46), Nylon 4/6, Glass Filled
Contact Material - Mating Beryllium Copper
Contact Material - Post Brass
Technical
Operating Temperature -55°C~105°C
Packaging Bulk
Published 2009
Series PGM
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Type PGA
Max Operating Temperature 105°C
Min Operating Temperature -55°C
Contact Finish - Mating Gold
Current Rating (Amps) 3A
Current Rating 3A
Pitch - Mating 0.100 2.54mm
Contact Finish - Post Tin
Lead Length 4.191mm
Termination Post Length 0.165 4.19mm
Pitch - Post 0.100 2.54mm
Dimensions
Contact Finish Thickness - Mating 10.0μin 0.25μm
Contact Finish Thickness - Post 200.0μin 5.08μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
