48-6554-10
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
CONN IC DIP SOCKET ZIF 48POS TIN
PDF
/
Buying Options
Total Price: USD $17.59
Unit Price: USD $17.5912
≥1 USD $17.5912
≥10 USD $15.40616
≥100 USD $14.740704
≥500 USD $14.265152
≥1000 USD $13.789776
≥3000 USD $13.028928
Inventory: 169
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Through Hole
Mounting Type Through Hole
Housing Material Polyphenylene Sulfide (PPS), Glass Filled
Number of Positions or Pins (Grid) 48 (2 x 24)
Contact Material - Mating Beryllium Copper
Contact Material - Post Beryllium Copper
Technical
Packaging Bulk
Published 1996
Series 55
JESD-609 Code e3
Feature Closed Frame
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type DIP, Socket
Type DIP, ZIF (ZIP), 0.6 (15.24mm) Row Spacing
Number of Positions 48
Number of Rows 2
Gender Female
Additional Feature STANDARD: UL 94V-0
Contact Finish - Mating Tin
Orientation Straight
Current Rating 1A
Pitch - Mating 0.100 2.54mm
Lead Pitch 2.54mm
Number of Contacts 48
PCB Contact Pattern RECTANGULAR
Operating Temperature (Max) 105°C
Body Breadth 0.9 inch
Body Depth 0.47 inch
Contact Style BELLOWED TYPE
Insulation Resistance 1GOhm
Row Spacing 15.24 mm
Mating Contact Pitch 0.1 inch
Dielectric Withstanding Voltage 1000VAC V
Termination Post Length 0.110 2.78mm
Pitch - Post 0.100 2.54mm
Dimensions
Height 11.9mm
Length 74.7mm
Width 22.9mm
Contact Finish Thickness - Mating 200.0μin 5.08μm
Contact Finish Thickness - Post 200.0μin 5.08μm
Compliance
Material Flammability Rating UL94 V-0
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
