48-6553-16
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
55 ROHS3Compliant 2013 Closed Frame DIP, ZIF (ZIP), 0.6 (15.24mm) Row Spacing Socket 1A 50.0muin 1.27mum
PDF
/
Buying Options
Total Price: USD $186.82
Unit Price: USD $186.821731
≥1 USD $186.821731
≥198 USD $74.543836
≥498 USD $72.053265
≥1002 USD $70.821765
Inventory: 2829
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Through Hole
Housing Material Polyphenylene Sulfide (PPS), Glass Filled
Number of Positions or Pins (Grid) 48 (2 x 24)
Contact Material - Mating Beryllium Copper
Contact Material - Post Beryllium Copper
Technical
Packaging Bulk
Published 2013
Series 55
Feature Closed Frame
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Type DIP, ZIF (ZIP), 0.6 (15.24mm) Row Spacing
Additional Feature STANDARD: UL 94V-0
Contact Finish - Mating Nickel Boron
Current Rating (Amps) 1A
Pitch - Mating 0.100 2.54mm
Number of Contacts 48
Contact Finish - Post Nickel Boron
Termination Post Length 0.110 2.78mm
Pitch - Post 0.100 2.54mm
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Contact Finish Thickness - Post 50.0μin 1.27μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
