44-6572-16
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
57 ROHS3Compliant 2005 RECTANGULAR DIP, ZIF (ZIP), 0.6 (15.24mm) Row Spacing Socket UL94V-0 200C 1A 1000VAC V
PDF
/
Buying Options
Total Price: USD $134.46
Unit Price: USD $134.455402
≥1 USD $134.455402
≥200 USD $53.649033
≥500 USD $51.856924
≥1000 USD $50.970717
Inventory: 966
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Post 200.0μin 5.08μm
Contact Finish Thickness - Mating 200.0μin 5.08μm
Technical
Pitch - Post 0.100 2.54mm
Termination Post Length 0.110 2.78mm
PCB Contact Row Spacing 0.6 mm
Dielectric Withstanding Voltage 1000VAC V
Mating Contact Pitch 0.1 inch
Insulation Resistance 1000000000Ohm
Contact Style SQ PIN-SKT
Body Depth 0.47 inch
Lead Length 2.794mm
Body Breadth 0.9 inch
Operating Temperature (Max) 200°C
PCB Contact Pattern RECTANGULAR
Number of Contacts 44
Body Length or Diameter 2.79 inch
Pitch - Mating 0.100 2.54mm
Current Rating 1A
Terminal Pitch 2.54mm
Contact Finish - Mating Tin
Additional Feature STANDARD: UL 94V-0
Number of Positions 44
Type DIP, ZIF (ZIP), 0.6 (15.24mm) Row Spacing
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Closed Frame
Series 57
Published 2005
Packaging Bulk
Physical
Contact Material - Post Beryllium Copper
Contact Material - Mating Beryllium Copper
Number of Positions or Pins (Grid) 44 (2 x 22)
Housing Material Polyphenylene Sulfide (PPS), Glass Filled
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 5 Weeks
