44-547-11
RoHS
RoHS compliant
RoHS compliantPackage SOIC
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
CONN SOCKET SOIC ZIF 44POS GOLD
PDF
/
Buying Options
Total Price: USD $446
Unit Price: USD $445.997382
≥1 USD $445.997382
≥200 USD $177.955718
≥500 USD $172.009594
≥1000 USD $169.071323
Inventory: 962
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Post 20.0μin 0.51μm
Contact Finish Thickness - Mating 20.0μin 0.51μm
Width 47.2mm
Length 85.3mm
Height 24.4mm
Technical
Pitch - Post 0.050 1.27mm
Termination Post Length 0.150 3.81mm
Number of Contacts 44
Pitch 1.27mm
Current Rating (Amps) 1A
Contact Finish - Mating Gold
Additional Feature STANDARD: UL 94V-0
Number of Positions 44
Type SOIC, ZIF (ZIP)
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Closed Frame
JESD-609 Code e4
Series 547
Published 2000
Packaging Bulk
Physical
Contact Material - Post Beryllium Copper
Contact Material - Mating Beryllium Copper
Number of Positions or Pins (Grid) 44 (2 x 22)
Housing Material Polyphenylene Sulfide (PPS), Glass Filled
Package / Case SOIC
Mounting Type Through Hole
Mount Through Hole
Contact Material Copper
Supply Chain
Factory Lead Time 5 Weeks
