44-3553-10
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
55 ROHS3Compliant 2013 Closed Frame DIP, ZIF (ZIP), 0.3 (7.62mm) Row Spacing Socket 1A 200.0muin 5.08mum
PDF
/
Inventory: 9829
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mounting Type Through Hole
Housing Material Polyphenylene Sulfide (PPS), Glass Filled
Number of Positions or Pins (Grid) 44 (2 x 22)
Contact Material - Mating Beryllium Copper
Contact Material - Post Beryllium Copper
Technical
Packaging Bulk
Published 2013
Pitch - Post 0.100 2.54mm
Termination Post Length 0.110 2.78mm
Number of Contacts 44
Pitch - Mating 0.100 2.54mm
Current Rating (Amps) 1A
Contact Finish - Mating Tin
Additional Feature STANDARD: UL 94V-0
Type DIP, ZIF (ZIP), 0.3 (7.62mm) Row Spacing
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Closed Frame
JESD-609 Code e3
Series 55
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Post 200.0μin 5.08μm
Contact Finish Thickness - Mating 200.0μin 5.08μm
