42-6556-20

Aries Electronics
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description IC & Component Sockets 42 SCKT RECEPT TIN WIRE WRAP
PDF
/
Inventory: 1903
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 4 Weeks

Physical

Contact Plating Gold, Tin
Mount Through Hole
Mounting Type Through Hole
Housing Material Polyphenylene Sulfide (PPS), Glass Filled
Number of Positions or Pins (Grid) 42 (2 x 21)
Contact Material - Mating Beryllium Copper
Contact Material - Post Brass

Technical

Packaging Bulk
Published 2006
Series 6556
JESD-609 Code e3
Feature Open Frame
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Wire Wrap
ECCN Code EAR99
Type DIP, 0.6 (15.24mm) Row Spacing
Number of Positions 42
Additional Feature STANDARD: UL 94V-0
Contact Finish - Mating Gold
Terminal Pitch 2.54mm
Current Rating 3A
Pitch - Mating 0.100 2.54mm
Body Length or Diameter 2.66 inch
Number of Contacts 42
Contact Finish - Post Tin
PCB Contact Pattern RECTANGULAR
Operating Temperature (Max) 105°C
Body Breadth 1.27 inch
Lead Length 7.1882mm
Body Depth 0.29 inch
Contact Style RND PIN-SKT
Mating Contact Pitch 0.1 inch
PCB Contact Row Spacing 0.6 mm
Termination Post Length 0.283 7.19mm
Pitch - Post 0.100 2.54mm

Dimensions

Contact Finish Thickness - Mating 30.0μin 0.76μm
Contact Finish Thickness - Post 200.0μin 5.08μm

Compliance

Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
