42-3574-16
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
IC & Component Sockets QUICK RELEASE 42 PIN NICKEL
PDF
/
Buying Options
Total Price: USD $128.35
Unit Price: USD $128.353043
≥1 USD $128.353043
≥200 USD $51.213603
≥500 USD $49.502895
≥1000 USD $48.657387
Inventory: 9677
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Housing Material Polyphenylene Sulfide (PPS), Glass Filled
Number of Positions or Pins (Grid) 42 (2 x 21)
Contact Material - Mating Beryllium Copper
Contact Material - Post Beryllium Copper
Technical
Packaging Bulk
Published 2005
Series 57
Feature Closed Frame
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Type DIP, ZIF (ZIP), 0.3 (7.62mm) Row Spacing
Number of Positions 42
Additional Feature STANDARD: UL 94V-0
Contact Finish - Mating Tin
Current Rating 1A
Pitch - Mating 0.100 2.54mm
Number of Contacts 42
Lead Length 2.794mm
Termination Post Length 0.110 2.78mm
Pitch - Post 0.100 2.54mm
Dimensions
Contact Finish Thickness - Mating 200.0μin 5.08μm
Contact Finish Thickness - Post 200.0μin 5.08μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
