36-6573-10
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
57 ROHS3Compliant 2005 RECTANGULAR DIP, ZIF (ZIP), 0.6 (15.24mm) Row Spacing Socket UL94V-0 105C 1A 1000VAC V
PDF
/
Buying Options
Total Price: USD $36.94
Unit Price: USD $36.939754
≥1 USD $36.939754
≥200 USD $14.739928
≥500 USD $14.247591
≥1000 USD $14.003391
Inventory: 937
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Housing Material Polyphenylene Sulfide (PPS), Glass Filled
Number of Positions or Pins (Grid) 36 (2 x 18)
Contact Material - Mating Beryllium Copper
Contact Material - Post Beryllium Copper
Technical
Packaging Bulk
Published 2005
Series 57
JESD-609 Code e3
Feature Closed Frame
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Type DIP, ZIF (ZIP), 0.6 (15.24mm) Row Spacing
Number of Positions 36
Additional Feature STANDARD: UL 94V-0
Contact Finish - Mating Tin
Terminal Pitch 2.54mm
Current Rating 1A
Pitch - Mating 0.100 2.54mm
Body Length or Diameter 2.39 inch
Number of Contacts 36
PCB Contact Pattern RECTANGULAR
Operating Temperature (Max) 105°C
Body Breadth 0.9 inch
Lead Length 2.794mm
Body Depth 0.47 inch
Contact Style SQ PIN-SKT
Insulation Resistance 1000000000Ohm
Mating Contact Pitch 0.1 inch
Dielectric Withstanding Voltage 1000VAC V
PCB Contact Row Spacing 0.6 mm
Termination Post Length 0.110 2.78mm
Pitch - Post 0.100 2.54mm
Dimensions
Contact Finish Thickness - Mating 200.0μin 5.08μm
Contact Finish Thickness - Post 200.0μin 5.08μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
