36-6553-11
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
55 ROHS3Compliant 2013 Closed Frame DIP, ZIF (ZIP), 0.6 (15.24mm) Row Spacing Socket 1A 50.0muin 1.27mum
PDF
/
Inventory: 999
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mounting Type Through Hole
Housing Material Polyphenylene Sulfide (PPS), Glass Filled
Number of Positions or Pins (Grid) 36 (2 x 18)
Contact Material - Mating Beryllium Copper
Contact Material - Post Beryllium Copper
Technical
Packaging Bulk
Published 2013
Series 55
JESD-609 Code e4
Feature Closed Frame
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Type DIP, ZIF (ZIP), 0.6 (15.24mm) Row Spacing
Additional Feature STANDARD: UL 94V-0
Contact Finish - Mating Nickel Boron
Current Rating (Amps) 1A
Pitch - Mating 0.100 2.54mm
Number of Contacts 36
Contact Finish - Post Nickel Boron
Termination Post Length 0.110 2.78mm
Pitch - Post 0.100 2.54mm
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Contact Finish Thickness - Post 50.0μin 1.27μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
