34-3513-10

Aries Electronics
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description IC & Component Sockets LO-PRO FILE COLLET SOLDER TAIL 34 PINS
PDF
/
Inventory: 5165
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0

Dimensions

Contact Finish Thickness - Post 200.0μin 5.08μm
Contact Finish Thickness - Mating 10.0μin 0.25μm

Technical

Pitch - Post 0.100 2.54mm
Termination Post Length 0.125 3.18mm
PCB Contact Row Spacing 0.3 mm
Mating Contact Pitch 0.1 inch
Contact Style RND PIN-SKT
Body Depth 0.165 inch
Lead Length 3.175mm
Body Breadth 0.4 inch
PCB Contact Pattern RECTANGULAR
Contact Finish - Post Tin
Number of Contacts 34
Lead Pitch 2.54mm
Body Length or Diameter 3.4 inch
Pitch - Mating 0.100 2.54mm
Current Rating 3A
Contact Finish - Mating Gold
Additional Feature STANDARD: UL 94V-0
Number of Rows 2
Number of Positions 34
Type DIP, 0.3 (7.62mm) Row Spacing
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Closed Frame
JESD-609 Code e3
Series Lo-PRO?file, 513
Published 2006
Packaging Bulk
Operating Temperature -55°C~105°C

Physical

Contact Material - Post Brass
Contact Material - Mating Beryllium Copper
Number of Positions or Pins (Grid) 34 (2 x 17)
Housing Material Polyamide (PA46), Nylon 4/6, Glass Filled
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 5 Weeks
