32-6511-11
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
STANDARD: UL 94V-0 ICs Socket
PDF
/
Inventory: 8440
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Housing Material Polyamide (PA46), Nylon 4/6, Glass Filled
Number of Positions or Pins (Grid) 32 (2 x 16)
Contact Material - Mating Phosphor Bronze
Contact Material - Post Phosphor Bronze
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2013
Series 511
JESD-609 Code e4
Feature Closed Frame
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Type DIP, 0.6 (15.24mm) Row Spacing
Additional Feature STANDARD: UL 94V-0
Contact Finish - Mating Gold
Terminal Pitch 2.54mm
Current Rating 1A
Pitch - Mating 0.100 2.54mm
Body Length or Diameter 1.65 inch
Number of Contacts 32
PCB Contact Pattern RECTANGULAR
Body Breadth 0.69 inch
Lead Length 3.81mm
Body Depth 0.3 inch
Contact Style SQ PIN-SKT
Mating Contact Pitch 0.1 inch
PCB Contact Row Spacing 0.6 mm
Termination Post Length 0.150 3.81mm
Pitch - Post 0.100 2.54mm
Dimensions
Contact Finish Thickness - Mating 10.0μin 0.25μm
Contact Finish Thickness - Post 10.0μin 0.25μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
