32-0518-10T
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
518 ROHS3Compliant 2006 Open Frame SIP Socket UL94V-0 3A 10.0muin 0.25mum
PDF
/
Inventory: 8040
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Number of Pins 32
Housing Material Polyamide (PA46), Nylon 4/6, Glass Filled
Number of Positions or Pins (Grid) 32 (1 x 32)
Contact Material - Mating Beryllium Copper
Contact Material - Post Brass
Technical
Packaging Bulk
Published 2006
Series 518
JESD-609 Code e3
Feature Open Frame
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Type SIP
Number of Rows 1
Additional Feature STANDARD: UL 94V-0
Contact Finish - Mating Gold
Current Rating 3A
Pitch - Mating 0.100 2.54mm
Lead Pitch 2.54mm
Number of Contacts 32
Contact Finish - Post Tin
Lead Length 3.175mm
Termination Post Length 0.125 3.18mm
Pitch - Post 0.100 2.54mm
Dimensions
Contact Finish Thickness - Mating 10.0μin 0.25μm
Contact Finish Thickness - Post 200.0μin 5.08μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
