32-0518-10H

Aries Electronics
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description 518 ROHS3Compliant 2006 RECTANGULAR SIP Socket UL94V-0 3A 3.2inch
PDF
/
Inventory: 3773
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 5 Weeks

Physical

Mount Through Hole
Mounting Type Through Hole
Number of Pins 32
Housing Material Polyamide (PA46), Nylon 4/6, Glass Filled
Number of Positions or Pins (Grid) 32 (1 x 32)
Contact Material - Mating Beryllium Copper
Contact Material - Post Brass

Technical

Packaging Bulk
Published 2006
Series 518
JESD-609 Code e3
Feature Open Frame
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Type SIP
Number of Rows 1
Additional Feature STANDARD: UL 94V-0
Contact Finish - Mating Gold
Current Rating 3A
Pitch - Mating 0.100 2.54mm
Body Length or Diameter 3.2 inch
Lead Pitch 2.54mm
Number of Contacts 32
Contact Finish - Post Tin
PCB Contact Pattern RECTANGULAR
Lead Length 3.175mm
Contact Style RND PIN-SKT
Termination Post Length 0.125 3.18mm
Pitch - Post 0.100 2.54mm

Dimensions

Contact Finish Thickness - Mating 10.0μin 0.25μm
Contact Finish Thickness - Post 200.0μin 5.08μm

Compliance

Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
