30-0501-30
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
IC & Component Sockets STRIP LINE BIFURCATE 30 PINS TIN
PDF
/
Buying Options
Total Price: USD $33.16
Unit Price: USD $33.159915
≥1 USD $33.159915
≥200 USD $13.231406
≥500 USD $12.788959
≥1000 USD $12.571018
Inventory: 7850
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Housing Material Polyamide (PA46), Nylon 4/6, Glass Filled
Number of Positions or Pins (Grid) 30 (1 x 30)
Contact Material - Mating Phosphor Bronze
Contact Material - Post Phosphor Bronze
Technical
Operating Temperature -55°C~105°C
Packaging Bulk
Published 2006
Series 501
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Wire Wrap
ECCN Code EAR99
Type SIP
Number of Positions 30
Number of Rows 1
Additional Feature STANDARD: UL 94V-0
Contact Finish - Mating Tin
Current Rating 1A
Pitch - Mating 0.100 2.54mm
Lead Pitch 2.54mm
Number of Contacts 30
Lead Length 17.526mm
Termination Post Length 0.690 17.52mm
Pitch - Post 0.100 2.54mm
Dimensions
Contact Finish Thickness - Mating 200.0μin 5.08μm
Contact Finish Thickness - Post 200.0μin 5.08μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
