29-0501-31
RoHS
RoHS compliant
RoHS compliantPackage SIP
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
501 ROHS3Compliant 2007 Gold SIP Socket UL94V-0 125C 1A 10.0muin 0.25mum
PDF
/
Inventory: 8616
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Post 10.0μin 0.25μm
Contact Finish Thickness - Mating 10.0μin 0.25μm
Technical
Pitch - Post 0.100 2.54mm
Termination Post Length 0.690 17.52mm
Lead Length 17.526mm
Contact Finish - Post Gold
Lead Pitch 2.54mm
Pitch - Mating 0.100 2.54mm
Current Rating 1A
Pitch 2.54mm
Current Rating (Amps) 1A
Contact Finish - Mating Gold
Number of Rows 1
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Number of Positions 29
Type SIP
Termination Wire Wrap
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 501
Published 2007
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Contact Material - Post Phosphor Bronze
Contact Material - Mating Phosphor Bronze
Number of Positions or Pins (Grid) 29 (1 x 29)
Housing Material Polyamide (PA46), Nylon 4/6, Glass Filled
Package / Case SIP
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold
Supply Chain
Factory Lead Time 7 Weeks
