29-0501-21
RoHS
RoHS compliant
RoHS compliantPackage SIP
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
501 ROHS3Compliant 2006 Gold SIP Socket UL94V-0 125C 1A 10.0muin 0.25mum
PDF
/
Buying Options
Total Price: USD $36.26
Unit Price: USD $36.258359
≥1 USD $36.258359
≥200 USD $14.468158
≥500 USD $13.983698
≥1000 USD $13.74475
Inventory: 9585
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Contact Plating Gold
Mount Through Hole
Mounting Type Through Hole
Package / Case SIP
Housing Material Polyamide (PA46), Nylon 4/6, Glass Filled
Number of Positions or Pins (Grid) 29 (1 x 29)
Contact Material - Mating Phosphor Bronze
Contact Material - Post Phosphor Bronze
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2006
Series 501
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Wire Wrap
Type SIP
Number of Positions 29
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Number of Rows 1
Contact Finish - Mating Gold
Current Rating (Amps) 1A
Pitch 2.54mm
Current Rating 1A
Pitch - Mating 0.100 2.54mm
Lead Pitch 2.54mm
Contact Finish - Post Gold
Lead Length 10.668mm
Termination Post Length 0.420 10.67mm
Pitch - Post 0.100 2.54mm
Dimensions
Contact Finish Thickness - Mating 10.0μin 0.25μm
Contact Finish Thickness - Post 10.0μin 0.25μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
