28-3573-16
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
57 ROHS3Compliant 2005 Closed Frame DIP, ZIF (ZIP), 0.3 (7.62mm) Row Spacing Socket UL94V-0 1A 50.0muin 1.27mum
PDF
/
Buying Options
Total Price: USD $85.7
Unit Price: USD $85.695609
≥1 USD $85.695609
≥198 USD $34.193168
≥495 USD $33.050945
≥1001 USD $32.486398
Inventory: 1375
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Contact Plating Nickel
Mount Through Hole
Mounting Type Through Hole
Housing Material Polyphenylene Sulfide (PPS), Glass Filled
Number of Positions or Pins (Grid) 28 (2 x 14)
Contact Material - Mating Beryllium Nickel
Contact Material - Post Beryllium Nickel
Technical
Packaging Bulk
Published 2005
Series 57
Feature Closed Frame
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Type DIP, ZIF (ZIP), 0.3 (7.62mm) Row Spacing
Number of Positions 28
Additional Feature STANDARD: UL 94V-0
Contact Finish - Mating Nickel Boron
Current Rating 1A
Pitch - Mating 0.100 2.54mm
Number of Contacts 28
Contact Finish - Post Nickel Boron
Lead Length 2.794mm
Termination Post Length 0.110 2.78mm
Pitch - Post 0.100 2.54mm
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Contact Finish Thickness - Post 50.0μin 1.27μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
